UNITÀ DI VENTILAZIONE CON RECUPERO DI CALORE DECENTRALIZZATE

PICO ULTRA PLUS + Ventilation unit with wall-mounted point heat recovery, with time band programming

PICO ULTRA PLUS+ is an innovative system designed to improve thermal comfort and air quality in residential environments.

PICO ULTRA PLUS+ is able to operate in both directions, which means it can be used to ventilate and recover the heat of the environment according to requirements. This allows a comfortable microclimate to be maintained in all seasons.

Energy Saving: This system is designed to maximize energy saving, thus reducing the costs associated with heating and cooling of indoor spaces. Thanks to its efficient operation, it contributes to reducing environmental impact.

Optimized Ventilation: PICO ULTRA PLUS + ensures effective ventilation and adequate air exchange inside the rooms, improving air quality and contributing to the well-being of the occupants.

High Efficiency: The vacuum extractor integrated in PICO ULTRA PLUS offers a high performance, with the extraction capacity that can reach up to 90%. This is made possible by the presence of a ceramic honeycomb heat exchanger, which maximizes thermal efficiency.

Easy Installation and Maintenance: PICO ULTRA PLUS is designed for easy installation and requires simple maintenance. This simplifies the management of the system, reducing maintenance costs over time.

Read more Read less
More details
Features
  • For wall installation
  • Front wall thickness 35 mm
  • Available with flow rates from 30 to 60 m³/h
  • Energy Class A
  • Wi-fi control mode 2.4 GHz via APP: local or remote connection
  • Integration Voice assistants and Google Home
  • Automatic closing damper
  • Functions: Comfort - CO2 threshold - Humidity threshold - Natural recirculation - Free Cooling - Free Heating - Night mode
  • MASTER function / SLAVE: Possibility to connect in cascade via WIFI up to 4 slaves
  • Slaves configurable in synchronous or asynchronous mode.
Models
Cod.: ACD100069
Cod.: ACD100070
Cod.: ACD100071
